Apple Juice Pomace Fruit Processing Line To Make Pectin Bag Packing

Ø Output: 1T/h;

Ø discharge accuracy: 80 mesh,

Ø power 18KW

Ø Volume: 10000L

Ø Double-layer insulation, 3mm inner wall, 50mm rock wool insulation in the middle, 1.5mm outer cover, manhole, cleaning ball, thermometer, inlet and outlet, etc.,

Ø steam valve group: filter, pressure reducing valve, regulating valve, stop valve, steam trap,

Ø Tubular heat exchanger: 2 sets of stainless steel tubular heat exchanger 6M2,

Ø centrifugal pump: 10T/H, head 24 meters, power 2.2kw

Ø Volume: 5000L

Ø Three-layer jacket, inner wall 5mm, jacket 3mm U-shaped coil, middle 50mm rock wool insulation, frame stirring, outsourcing 1.5mm, manhole, cleaning ball, thermometer, sampling valve, inlet and outlet,

Ø steam heating, steam valve group

Ø Capacity: 5T/h;

Ø Output pressure:0.6MPA

Ø Power: 4kw;

Ø Capacity: 5T/h

Ø Tube structure,

Ø feed temperature 100-120℃, outlet temperature 50-80℃

Ø Capacity: 5T/h

Ø Three-phase separation structure (liquid phase, solid phase),

Ø the diameter of the turning stock is 450mm, the rotation speed is 3600rpm, and the power is 52KW

Ø Volume: 500L

• 304 stainless steel material,
• inclined bottom structure, movable cover

Ø Capacity: 5T/h

Ø Head:24m

Ø Power 2.2KW

Ø Capacity: 3T/h

Ø Solid-liquid separation,

Ø speed 8100rpm, power 22KW

Ø Volume: 3000L

Ø Double-layer insulation, inner wall 3mm, middle 50mm rock wool insulation, outsourcing 1.5mm,

Ø paddle stirring, manhole, cleaning ball, thermometer, import and export, etc.

Ø Capacity: 3T/h

Ø Head:24m

Ø Power 2.2KW

Ø Siemens PLC, touch screen,

Ø Schneider Omron low-voltage components,

Ø stainless steel control cabinet

Ø Volume: 3000L

Ø Three-layer jacket, inner wall 3mm, jacket 3mm U-shaped coil, middle 50mm rock wool insulation,

Ø frame stirring, outsourcing 1.5mm, manhole, cleaning ball, thermometer, sampling valve, inlet and outlet, etc.

Ø 100L heat preservation tank,

Ø steam valve group: filter, pressure reducing valve, regulating valve, globe valve, steam trap,

Ø plate heat exchanger: brazed plate heat exchanger 6M2

Ø Centrifugal pump: 5T/H, head 24 meters

Ø Capacity: 3T/h;

Ø Output pressure:0.6MPA

Ø Power: 3.7kw;

Ø Capacity: 3T/h

Ø The filter area is 20 square meters,

Ø size of the filter plate: 700*700mm,

Ø automatically pulling plate

Ø Volume: 500L

Ø Double-layer insulation, inner wall 3mm, middle 50mm rock wool insulation, outsourcing 1.5mm,

Ø paddle stirring, manhole, cleaning ball, thermometer, import and export, etc.

Ø Capacity: 3T/h

Ø Head:24m

Ø Power 2.2KW

Ø Capacity: 3T/h

Ø 50 square ceramic membrane

Ø filter precision 50nm,

Ø power 7.5kw

Ø Volume: 3000L

• 304 stainless steel material,
• inclined bottom structure, movable cover

Ø Capacity: 3T/h

Ø Head:24m

Ø Power 2.2KW

Ø Capacity: 2000L/h

Ø Double-effect evaporator, forced circulation structure, including heating system, evaporation system, condensation system, vacuum system, control system, etc.

Ø Volume: 3000L

• 304 stainless steel material,
• inclined bottom structure, movable cover

Ø Capacity: 5T/h;

Ø Output pressure:0.6MPA

Ø Power: 4kw;

Ø Siemens PLC, touch screen,

Ø Schneider Omron low-voltage components,

Ø stainless steel control cabinet
